Yarn Singeing

show general information
filter yarn type
  • Spun
  • Filament
  • GSX3-E

    Yarn singeing and precision winding machine

    • Tubes

      or cops are the most flexible base for a wide range of package shapes (e.g.: cylindrical - no taper / biconical - double taper / single taper / bottle shape), depending on the winding unit (type of winding)

    • Cones

      for a conical package shape

    • COCotton

      Natural fibre from the cotton plant which is spun into fine yarn.

    • SpunYarnSpun yarn

      Textile yarn spun and twisted from staple length fiber, either natural or synthetic.

    The SSM yarn gas singeing and precision winding machine GSX3-E assures high customer benefits and top qualities. Thanks to optimised yarn path, even the finest yarn counts or single yarns can be processed to best effect. Highest flexibility with individual spindle drive helps to increase significantly the production efficiency:

    show more textshow less text

    Technical data GSX3-E

    Types of winding

    DIGICONE® or precision

    Mechanical speed

    up to 1500 m/min (process speed depending on process parameters)

    Package shape

    cylindrical or conical (up to 4° 20’; other conicities upon request)

    Traverse length

    25…152 mm infinitely variable (up to 6”)

    Take-up diameter

    up to 280 mm

    Package weight

    up to 3.5 kg

    Supply package diameter

    up to 280 mm

    Yarns

    cotton, rayon staple fibre yarns, blends and other spun yarns

    Count

    Ne 10/2…160/2 (Nm 16/2…270/2) (other yarn counts on request)

    Take-up tubes

    cylindrical and cones up to 4° 20’

    max. tube length 170 mm, min. base diameter 38 mm (smaller diameters on request)

    Layout

    double sided

    min. / max. N° of spindles

    2 x 6 / 2 x 42

    Gauge

    360 mm

    Drive

    individual per spindle

    Installed power

    ~170 W per spindle

    Power consumption

    ~110 W per spindle (depending on speed, yarn count, yarn tension)

    Power input per machine

    Dust suction: 1100 W to 12 000 W*
    Gas / air mixing device: 1100 W to 3000 W*

    (*depending on number of spindles)
    Travelling blower (option): 1100 W to 2200 W high pressure blower for air supply

    Gas consumption

    Butan / Propan: 40...70 gr/h per spindle (depending on yarn)
    Natural / City gas: 45...75 gr/h per spindle (depending on yarn)

    show more factsshow less facts

    Downloads

  • GSX3-GD

    Yarn singeing and random winding machine

    • Tubes

      or cops are the most flexible base for a wide range of package shapes (e.g.: cylindrical - no taper / biconical - double taper / single taper / bottle shape), depending on the winding unit (type of winding)

    • Cones

      for a conical package shape

    • COCotton

      Natural fibre from the cotton plant which is spun into fine yarn.

    • SpunYarnSpun yarn

      Textile yarn spun and twisted from staple length fiber, either natural or synthetic.

    The SSM yarn gas singeing machine GSX3 assures high customer benefits and top qualities. Thanks to optimised yarn path, even the finest yarn counts or single yarns can be processed to best effect. Highest flexibility with individual spindle drive helps to increase significantly the production efficiency:

    show more textshow less text

    Technical data GSX3-GD

    Types of winding

    drum with ceramic inserts, random

    Mechanical speed

    up to 1500 m/min (process speed depending on process parameters)

    Package shape

    cylindrical or conical (up to 5° 57’)

    Traverse length

    152 mm (6”)

    Take-up diameter

    up to 280 mm

    Package weight

    up to 3.5 kg

    Supply package diameter

    up to 280 mm

    Yarns

    cotton, rayon staple fibre yarns, blends and other spun yarns

    Count

    Ne 10/2…160/2 (Nm 16/2…270/2) (other yarn counts on request)

    Take-up tubes

    cylindrical and cones up to 4° 20’

    Layout

    double sided

    min. / max. N° of spindles

    2 x 6 / 2 x 42

    Gauge

    360 mm

    Drive

    individual per spindle

    Installed power

    ~135 W per spindle

    Power consumption

    ~90 W per spindle (depending on speed, yarn count, yarn tension, anti pattering)

    Power input per machine

    Dust suction: 1100 W to 12 000 W*
    Gas / air mixing device: 1100 W to 3000 W*

    (*depending on number of spindles)
    Travelling blower (option): 1100 W to 2200 W high pressure blower for air supply

    Gas consumption

    Butan / Propan: 40...70 gr/h per spindle (depending on yarn)

    Natural / City gas: 45...75 gr/h per spindle (depending on yarn)

    show more factsshow less facts
